5Ton Single Girder eot Grab or Grapple or Bucket Crane

LZ type electric single girder grab crane is LD model electric single girder overhead crane matched with grab electric hoist trolley,the grab bucket is four rope grab bucket,it is one kind of lifting equipment that is widely used in factories, warehouses and material yards for lifting bulk goods.

Send Inquiry

Simple description of Single girder overhead crane with grab:

10 Ton Suspension Overhead Crane With Grab Bucket is designed and manufactured strictly conforming to FEM/DIN standard and adopts 8 patent technologies. To achieve excellent performance, reliable quality and long durability matching advanced design, several main components adopt original imported international famous brands such as Schneider, Siemens, ABB, SEW, France Cable etc. Meanwhile, modular manufacturing process leads to high generality components, less wearing parts, high maintenance-free rate, thus our 10 Ton Suspension Overhead Crane With Grab Bucket share a long service life with stable and outstanding performance.

10 Ton Suspension Overhead Crane With Grab Bucket consists of main gieder, hoist, end girder, hook, reducer, wireless control system.

Our advantage of 10 Ton Suspension Overhead Crane With Grab Bucket:

1. International advanced design
2. Compact and reasonable structure
3. Light deadweight
4. Easy operation
5. Superior configuration
6. Low noise
7. Energy saving

Sales service:

1. Consulting for best solution
2. Professional advice for type selection
3. Experienced experts’ on-site guidance for installation and commissioning
4. Free spare parts within warranty duration
5. On-line technical support for any time

The basic parameter of this crane parts is as following:

Lifting weight(t) 3 5
Span(m) 10.5~31.5
Max Lifting height(m) Main Hook 6~30
Auxiliary Hook 6~30
Working class A3 A4
Speed(m/min) Main Hoisting 8,8/0.8 8,8/0.8
Speed(m/min) Auxiliary Lifting \ \
Speed(m/min) Trolley Cross Traveling 20,2~20
Speed(m/min) Crane Long Traveling 30,3~30
Motor Type Squirrel cage motor
Motor (Kw) Main Hoisting 4.5 7.5
Auxiliary Lifting \ \
Trolley Cross Traveling 2*0.4,2*0.8,2*1.5
Crane Long Traveling 2*0.8,2*1.5,2*2.2
Control mode Pendent line control,Remote control,Cabin control
Recommended Rail model 24kgs/m 30kgs/m
Power source 3Ph A.C 50Hz 380V

FAQ:

Q. What’s the information should I provide when inquiry?
More details or drawings, better.
A: Lift capacity B: span C: lift height D: power source other specials
you give us will be more appreciated.

Q. How many operating methods for my selection?
Standard operating methods:
A: pendent controller with push buttons .B: remote control with push buttons C: cabin(space capsule seat) control with joystick. Choose any type as you like.

Q. Can this type of work in a hazardous environment?
A: Sure! We can customize for you, acid proof or explosion-proof,
no problem with that.

Q. Can you provide the serious lifting tools?
A: Sure, we can provide any lift tools such as lift sling belt, lift clamp, grab,
magnet or other specials as your requirement!

Q. What Safety device are equipped with your cranes?
A: Overload limiter, Limit Switch (lifting and traveling), Interlock protection device.
