Product introduction:

LB type explosion-proof electric single girder crane is improved on the basis of “LD”, Ex is an explosion-proof public sign, and explosion-proof bridge cranes are based on GB3836.1-2000 “Explosion-proof electrical equipment for explosive gas atmospheres*** Part: General requirements” and GB3836.2-2000 “Explosion-proof Electrical Equipment for Explosive Gas Atmosphere Part Two: Explosion-proof Type “d”” stipulates that when the motor and electrical appliance are of the explosion-proof type, and the explosion-proof level is ExdⅡCT4, the operating mechanism shall be subjected to spark-proof treatment. The whole machine complies with the requirements of JB/T5897-2006 “Explosion-proof Bridge Crane”, and the explosion-proof grades are ExdⅡBT4 and ExdⅡCT4 respectively.

Send Inquiry

Technical parameters:

Explosion proof Single Girder Overhead Crane
Crane Traveling Mechanism Traveling Speed m/min 20
Reducer Ratio i 58.95
Motor Type Soft starting Conic rotor squirrel cage motor
Power KW 0.8×2,1.5×2,2.2×2
RPM r/min 1380
Lifting Mechanism (Electric Hoist) Hoist Type HB, BCD, BMD
Capacity t 1,2,3,5,10,16
Lifting Speed m/min 8/0.8,7/0.7,3.5/0.35 8,7,3.5
Lifting Height m 6, 9, 12, 18, 24
Traveling Speed m/min 20
Motor Conic rotor squirrel cage motor
Work Duty A3 A4
Power Supply 380V, 50Hz, Three Phase
Diameter of Wheel Φ270mm,Φ400mm
Width of Track 37mm~70mm
Explosion-proof Grade ExdⅡBT4/ExdⅡCT4
