LB Explosion Proof Type Single Girder Overhead Crane

The LB type explosion-proof electric single-girder bridge crane (hereinafter referred to as the crane) is designed and manufactured according to the standard JB/T10219-2000 and is used in conjunction with the electric hoist in the form of BH, BMH, BCD, BMD, HB, etc., to become a track-shaped Light and small crane, its suitable lifting weight is 1~10 tons, the applicable span is 7.5-22. 5 meters and the working environment temperature is in the range of -20℃–+40℃.
In order to facilitate the user, there are two control modes: ground and control room. The control room is also equipped with two modes of opening doors on the end and side for users to choose and use. (Under normal circumstances, it is in the form of ground operation)

Send Inquiry

The LB type explosion-proof electric single-girder crane produced by our company is based on the national standard GB3836. 1-2000 “Explosion-proof electrical equipment for explosive environments Part 1: General requirements”, GB3836. 2-2000 “Explosion-proof electrical equipment for explosive environments 1 Part 2: Explosion-proof “d” regulations and dIICT4 and dIIBT4 explosion-proof single-beam cranes. The explosion-proof motors and explosion-proof electrical appliances used in this product have obtained the explosion-proof certificate issued by the National Explosion-proof Electrical Product Quality Supervision and Inspection Center. Manufacturing license issued by the State Administration of Technology Supervision. This product is suitable for lifting and lowering heavy objects in the factory when there is an explosive mixture of flammable gas, steam, and air specified in the table to ensure sufficient safety.
