Features:
1 Heavy class A5, A6, A7 and High efficiency
2 Forged wheel set, machined boring assembly, high assembly accuracy and long service life
3 Adopts to various working conditions
4 Reasonable structure and strong rigidity
5 The speed can be frequency inverter control.
6 Control method is an optional cabin, remote or pendant control.
7 Depending on lifting material, the crane can be equipped with hanging beam magnet or magnet chuck or Grab or Chook.
8 Crane is equipped with all moving limit switches, loading limits and other safety devices.
Applications:
Manufacturing workshop, metallurgy, petroleum, petrochemicals, ports, railway, civil aviation, power station, food industry, paper making, building material, warehouses and other material handling applications.
According to the degree of heavy use, this series of cranes are divided into two basic working levels: intermediate (A5) and heavy (A6). If necessary, they can also be designed and manufactured as light (A1~A3) or super heavy (A7~A8).
Intermediate working level (A5): The electric motor’s connection duration rate JC=25%, used in less frequent use occasions, such as paper-making workshops, steel pipe workshops, tower workshops, etc.
Heavy-duty level (A6): The motor’s power connection duration rate JC=40%, used in more frequent applications, such as pipe pile workshops, telephone pole workshops, etc. For heavy-duty cranes, the trolley operating mechanism and auxiliary hoisting mechanism are designed according to the intermediate level.
