Mechanical Parts：
1.Capacity:2,3,5,10t
2.Span: 7.5-28.5m
3.Lifting height: 9,12,15,18,20m
4.Lifting speed:7,8m/min
5.Widely used in: Steel factories, Working at work level A6, working environment temperature ≤60℃, relative humidity ≤85﹪, altitude below 2000m, working under non-corrosive medium environment conditions.
Parameter Table
| Lifting weight(T) |
1 |
2 |
3 |
5 |
10 |
| Span(m) |
7.5-28.5 |
| Max Lifting height(m) |
9,12,15,18,20 |
| Working class |
A6 |
| Main Hoisting Speed(m/min) |
8,7 |
| Trolley Cross Traveling Speed(m/min) |
20 |
| Crane Long Traveling Speed(m/min) |
30,3~30(frequency inverter) |
| Motor Type |
Squirrel cage motor |
| Motor (Kw) |
Main Hoisting |
1.5 |
3 |
4.5 |
7.5 |
13 |
|
Trolley Cross Traveling |
1*0.4,1*0.8,2*0.8 |
|
Crane Long Traveling |
2*0.4,2*0.8,2*1.5 |
| Control mode |
Pendent line control,Remote control |
| Recommended Rail model |
I20a~45c,I40b~63c |
| Power source |
3Ph A.C 50Hz 380V
|
Safety System:
1.Overload protection
2.Long and cross travel limited by means of preliminary and final limit switches or Wireless anti-collision device
3.Voltage lower protection system
4.Current overload protection system
