Product description of single lifting speed electric wire rope hoist:
Single lifting speed Model electric wire rope hoist can provide a stable speed, it can do precise loading and unloading, mounding of sand box, maintenance of machine tools, etc. It can meet the needs of ordinary jobs and is cheap.It is widely used in factories, mines, harbours, warehouse, cargo storage areas and shops, essential in raising working efficiency and improving working conditions.
Product feature of single lifting speed electric wire rope hoist:
1.Lifting speed: Single lifting speed
2.Trolley travelling speed: 20m/min
3.Working class: M3~M4
4.Control method: pendant control+ remote control
5, Full safety system as follows:
Weight overload protection
Emergency stop system
Over current protection
Short-circuit protection
Phase sequence protection
Zero position protection
Voltage loss protection
Overhigh lift and overlow lift limit swit
Main Product:
Henan Mine Cranes meet the factory, workshop, port, mining, waste disposal, goods scattered, petrochemical, aerospace, military and other industries of universal bridge crane, overhead crane price 20 ton 5ton, eot crane, door crane, universal gantry crane, rubber tyre and rail mounted container gantry crane, four link type portal crane, quayside container crane, crane, crane hook, mining grab crane, gantry crane, ship loader, grab bucket ship unloader, stacker reclaimer, dredger, mobile platforms and other types of hydraulic crane technical requirements.
Advantages:
The 2,700-plus-member factory covers over 680,000 square meters and has a total asset of 660 million CNY. The 1,200-plus equipment enable the company to independently conduct over 20 technological flows, including lathing, milling, planning and grinding. The 180-plus intermediate and senor technical staff are responsible for R&D and production of all the products. The products have passed CE SGS TUV BV and CU-TR verification, and factory passed ISO9001-2008 international certification, IS014001:1996 environmental and ISO28001-2001 quality, health and safety certification. Our company has perfect quality-control system, strict and comprehensive management system, strong production capability and advanced test measures, guaranteeing high quality, output, competitiveness and market share.
Technical parameters:
| Type |
CD MD |
| Lifting weight(t) |
1,2,3,5 |
10 |
16 |
| Lifting height(m) |
6/9/12/16/24/30 |
9/12/18/24/30 |
9/12/16/20/24/30 |
| Hoisting speed(m/min) |
8(0.8/8) |
7(0.7/7) |
3.5(0.35/3.5) |
| Running speed(m/min) |
20 |
20 |
20 |
| Steel wire
rope type |
specification |
6×37+1 |
| H beam orbit model |
16-45c |
30T-45c |
30T-45C |
| Minimum curvature radius(m) |
1.5-6 |
3.5-9 |
3.5-6 |
| Hoisting motor |
Type |
ZD1(ZDS1) |
ZDI(ZDS1) |
ZD1(ZDS1) |
|
Power(KW) |
1.5/3/4.5/7.5 |
13(1.5/13) |
18.5(2.2/18.5) |
|
Rotation speed(r/min) |
1380 |
1380 |
1380 |
|
Current(A) |
4.3,7.6,11,18 |
30 |
30 |
| Running speed |
Type |
ZDY11,12,21-4 |
ZDY21-4 |
ZDY21-4 |
|
Power(KW) |
0.2,0.4,0.8 |
1.5*2 |
0.8*2 |
Installation Service:
Crane installation service for Henan Mining Crane Co., Ltd.
Henan Mining Crane Co., Ltd. can not only provide electric hoists, but also electric hoist solutions. First, we will provide electric hoist design, electric hoist manual, electric hoist drawings, electric hoist wiring diagram, electric hoist electrical diagram and electric hoist crane safety Before or after delivery of the video, our technicians will supervise the installation according to the documents. Of course, customers can install it according to their own requirements.
After the installation is complete, our technicians will instruct to carry out the load test in accordance with the electric hoist load test procedure, followed by electric hoist operator training and electric hoist maintenance training. All procedures will be carried out according to the electric hoist training video and electric hoist training PowerPoint.
The cranes of Henan Mining Crane Co., Ltd. have won many honors in the certification of different electric hoist types
If you want to know more about electric hoist, please find electric hoist accessories, electric hoist pdf, electric hoist catalog from the download center to obtain mobile electric hoist specifications and electric hoist regulations.
