Features：
1.Light structure,easy installation and maintenance
2.Reasonable structure,strong bearing capacity
3.Low noise, soft starting and stopping
4.Safe and reliable operation
5.Low cost maintenance, long working life
Parameter Table
| Lifting weight(T) |
1 |
2 |
3 |
5 |
10 |
| Span(m) |
3~16 |
| Max Lifting height(m) |
3,6,9,12,18 |
| Working class |
A5,A6 |
| Main Hoisting Speed(m/min) |
8,8/0.8;7,7/0.7 |
| Trolley Cross Traveling Speed(m/min) |
20,2~20(frequency inverter) |
| Crane Long Traveling Speed(m/min) |
30,3~30(frequency inverter) |
| Motor Type |
Squirrel cage motor |
| Motor (Kw) |
Main Hoisting |
1.5 |
3 |
4.5 |
7.5 |
13 |
|
Trolley Cross Traveling |
1*0.4,1*0.8,2*0.8 |
|
Crane Long Traveling |
2*0.4,2*0.8,2*1.5 |
| Control mode |
Pendent line control,Remote control |
| Recommended Rail model |
I20a~45c,I40b~63c |
| Power source |
3Ph A.C 50Hz 380V |
Safety System:
1.All movements can be switched off by actuating the emergency-off switch at the control station via a main contact
2.High quality long time bearing polyurethane materials buffer fixed at the end of trolley travelling and crane travelling to prevent over traveling
3.Safety hook latch used for avoiding the lifted material out off from the hook
